Launch
- Announced
- 2020, August 05
- Status
- Available. Released 2020, August 21
Body
- Dimensions
- 164.8 x 77.2 x 8.1 mm (6.49 x 3.04 x 0.32 in)
- Weight
- 208 g (7.34 oz)
- Build
- Glass front (Gorilla Glass Victus), glass back (Gorilla Glass Victus), stainless steel frame
- Sim
- Single SIM (Nano-SIM and/or eSIM) or Hybrid Dual SIM (Nano-SIM, dual stand-by)
-
- Samsung Pay (Visa, MasterCard certified) IP68 dust/water resistant (up to 1.5m for 30 mins) Stylus, 9ms latency (Bluetooth integration, accelerometer, gyro)
Display
- Type
- Dynamic AMOLED 2X capacitive touchscreen, 16M colors
- Size
- 6.9 inches, 116.7 cm2 (~91.7% screen-to-body ratio)
- Resolution
- 1440 x 3088 pixels (~496 ppi density)
- Protection
- Corning Gorilla Glass Victus
-
- HDR10+ Always-on display 120Hz@FHD/60Hz@QHD refresh rate
Platform
- Os
- Android 10, One UI 2.5
- Chipset
- Exynos 990 (7 nm+) - GlobalQualcomm SM8250 Snapdragon 865+ (7 nm+) - USA
- Cpu
- Octa-core (2x2.73 GHz Mongoose M5 & 2x2.50 GHz Cortex-A76 & 4x2.0 GHz Cortex-A55) - GlobalOcta-core (1x3.0 GHz Kryo 585 & 3x2.42 GHz Kryo 585 & 4x1.8 GHz Kryo 585) - USA
- Gpu
- Mali-G77 MP11 - GlobalAdreno 650 - USA
Memory
- Card slot
- microSDXC (uses shared SIM slot)
- Internal
- 128GB 12GB RAM, 256GB 12GB RAM, 512GB 12GB RAM
-
- UFS 3.0
Main camera
- Triple
- 108 MP, f/1.8, 26mm (wide), 1/1.33", 0.8µm, PDAF, Laser AF, OIS 12 MP, f/3.0, 120mm (periscope telephoto), 1.0µm, PDAF, OIS, 5x optical zoom, 50x hybrid zoom 12 MP, f/2.2, 120˚, 13mm (ultrawide), 1/2.55", 1.4µm
- Features
- LED flash, auto-HDR, panorama
- Video
- 8K@24fps, 4K@30/60fps, 1080p@30/60/240fps, 720p@960fps, HDR10+, stereo sound rec., gyro-EIS & OIS
Selfie camera
- Single
- 10 MP, f/2.2, 26mm (wide), 1/3.2", 1.22µm, Dual Pixel PDAF
- Features
- Dual video call, Auto-HDR
- Video
- 4K@30/60fps, 1080p@30fps
Sound
- Loudspeaker
- Yes, with stereo speakers
- 3.5mm jack
- No
-
- 32-bit/384kHz audio Tuned by AKG
Comms
- Wlan
- Wi-Fi 802.11 a/b/g/n/ac/6, dual-band, Wi-Fi Direct, hotspot
- Bluetooth
- 5.0, A2DP, LE, aptX
- Gps
- Yes, with A-GPS, GLONASS, BDS, GALILEO
- Nfc
- Yes
- Radio
- FM radio (Snapdragon model only; market/operator dependent)
- Usb
- 3.2, Type-C 1.0 reversible connector, USB On-The-Go
Features
- Sensors
- Fingerprint (under display, ultrasonic), accelerometer, gyro, proximity, compass, barometer
-
- Samsung Wireless DeX (desktop experience support) ANT+ Bixby natural language commands and dictation
Battery
- Type
- Li-Ion 4500 mAh, non-removable
- Charging
- Fast charging 25W USB Power Delivery 3.0 Fast Qi/PMA wireless charging 15W Reverse wireless charging 4.5W
Misc
- Colors
- Mystic Bronze, Mystic Black, Mystic White
- Models
- SM-N986B, SM-N986B/DS, SM-N986U, SM-N986U1, SM-N986W
- Sar
- 0.71 W/kg (head) 1.18 W/kg (body)
- Sar eu
- 0.34 W/kg (head) 1.47 W/kg (body)
- Price
- $ 1,299.99 / £ 1,149.99 / € 1,091.38
Tests
- Performance
- AnTuTu: 508760 (v8) GeekBench: 2603 (v5.1) GFXBench: 42fps (ES 3.1 onscreen)
- Display
- Contrast ratio: Infinite (nominal)
- Camera
- Photo / Video
- Loudspeaker
- -27.8 LUFS (Good)
- Battery life
- Endurance rating 88h
Network
- Technology
- GSM / CDMA / HSPA / EVDO / LTE / 5G
- 2g bands
- GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only)
-
- CDMA 800 / 1900
- 3g bands
- HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
-
- CDMA2000 1xEV-DO
- 4g bands
- 1, 2, 3, 4, 5, 7, 8, 12, 13, 14, 18, 19, 20, 25, 26, 28, 29, 30, 38, 39, 40, 41, 46, 48, 66, 71 - SM-N986U
- 5g bands
- 2, 5, 41, 66, 71, 260, 261 SA/NSA/Sub6/mmWave - SM-N986U
- Speed
- HSPA 42.2/5.76 Mbps, LTE-A (7CA) Cat20 2000/200 Mbps, 5G
